Hiding loudspeakers has become relatively easy. Hiding serious bass is another matter.
Architectural speakers can disappear behind paintable grilles without turning a room into an equipment showroom, but subwoofers still need large drivers, sufficient enclosure volume, plenty of power, and somewhere for all that energy to go. That usually means surrendering floor space to a large box or planning the bass system before anyone starts hanging drywall.
Monitor Audio expanded its Creator Series at CEDIA 2026 with three new in-wall subwoofer systems designed to address that problem. The WS1-W10, WS2-W12, and WS3-W12 use 10- or 12-inch low-profile drivers, purpose-built enclosure solutions, and dedicated DSP amplification, extending the same Tier 1, Tier 2, and Tier 3 structure already used throughout the company’s Creator architectural speaker lineup.
The systems start at $2,450 and climb to $6,150 for the flagship WS3-W12. None of them qualifies as inexpensive bass, but nobody shops for a high-performance subwoofer that gets buried inside the wall because they were looking for the easy route.
Monitor Audio WS1-W10
The WS1-W10 is the most flexible model in the new range and the one most likely to work in an existing room. It uses a 10-inch C-CAM low-profile, high-excursion driver with an 88mm mounting depth and can be installed either with Monitor Audio’s dedicated WS1-W10 BOX or without a back box in an infinite-baffle configuration.
That second option is important for retrofit projects where there may be enough open cavity volume for the subwoofer but not enough room for a long dedicated enclosure. With the WS1-W10 BOX, Monitor Audio specifies an installed frequency response of 27 Hz to 250 Hz at -6 dB; in an infinite-baffle installation, the claimed low-frequency extension reaches 22 Hz.
Amplification comes from the new IA500-S, a 1U Class D DSP amplifier that delivers 250 watts into the WS1-W10. It includes Impact, Movie, and Music DSP presets, along with level, crossover, and phase controls.
The complete WS1-W10 System is $2,450. Monitor Audio also sells the individual WS1-W10 for $800, the WS1-W10 BOX for $400, and the IA500-S for $1,250, giving integrators considerably more freedom when specifying the entry-level system.
Monitor Audio WS2-W12
The WS2-W12 moves to a 12-inch C-CAM RST II low-profile, high-excursion driver and is intended primarily for premium media rooms and home theaters where the installation can be planned before construction is finished.
Unlike the WS1-W10, the Tier 2 design is engineered around its matched sealed enclosure. Monitor Audio uses an internally partitioned cabinet to provide the driver with a defined acoustic volume while reducing unwanted vibration within the surrounding structure.
The WS2-W12 is rated for 500 watts continuous, with a claimed installed frequency response of 25 Hz to 250 Hz at -6 dB and maximum peak output of 115.3 dB. Despite the larger driver, mounting depth at the front is only 87mm.
The same IA500-S amplifier used with the WS1-W10 delivers its full 500 watts into the 3-ohm WS2-W12 load. The complete WS2-W12 System costs $2,950.
Monitor Audio WS3-W12
The WS3-W12 is the flagship and the model aimed squarely at dedicated high-performance theaters. It retains the 12-inch C-CAM RST II architecture but adds a more powerful motor system, 750-watt continuous power handling, and a considerably more elaborate rear enclosure.
Monitor Audio constructs the enclosure from metal and wood with internal bracing designed to maximize usable acoustic volume while limiting unwanted vibration. Claimed installed frequency response is 23 Hz to 250 Hz at -6 dB, with maximum peak output rated at 116.1 dB.
Power comes from the IA750-2, Monitor Audio’s two-channel DSP amplifier, with 750 watts available for the WS3-W12. The amplifier can support more complex system configurations as well, making the flagship better suited to installations where multiple architectural subwoofers are part of the plan.
The complete WS3-W12 System is $6,150. That will certainly get the interior designer’s attention, although at least they won’t have to look at the subwoofer afterward.
Why Is the Creator Approach Different?
In-wall subwoofers are not new, and Monitor Audio is hardly the first manufacturer to discover that home theater owners would rather feel a subwoofer than stare at one.
What makes the new Creator range interesting is how closely the bass systems follow the structure of the rest of the Creator ecosystem. Instead of introducing one architectural subwoofer and expecting it to cover every room and budget, Monitor Audio offers three clearly defined performance levels with amplification and installation hardware engineered around each application.
That simplifies system specification. An installer building around Tier 1 Creator speakers has an obvious corresponding bass solution, while more ambitious Tier 2 and Tier 3 theaters can move up in output and enclosure sophistication without switching to an unrelated product family.
The WS1-W10 is particularly clever because it preserves retrofit flexibility while the two 12-inch models prioritize predictable acoustic performance from purpose-designed enclosures. Monitor Audio has essentially separated the range by how the room will be built as much as by how loud the customer wants it to play.
There is one unavoidable caveat. Once an architectural subwoofer is installed, moving it three feet to deal with a nasty room mode is no longer an afternoon project. Careful placement, calibration, and in many rooms multiple subwoofers remain important regardless of how sophisticated the hardware becomes.
Three Competitors We Know
We’ve covered and heard enough architectural subwoofers at eCoustics to know that Monitor Audio is entering a category with some very serious competition.
At $1,999 or $2,999, SVS 3000 In-Wall Subwoofers feature a sealed aluminum enclosure with single or dual 9-inch high-excursion drivers powered by an external 800-watt RMS amplifier with DSP and app-based control. SVS rates it to 22 Hz at ±3 dB, and we’ve heard enough of SVS 3000 Series subwoofers to know that its relatively attainable price does not translate into polite bass.
The Theory Audio Design iws12-6 and iws12-9 attack the problem from a higher-output professional audio direction. Both use a 12-inch long-throw driver and require Theory’s Amplified Loudspeaker Controller, while the iws12-6 is designed around deeper 2×6 wall construction. We’ve heard Theory’s architectural systems at CEDIA Expos over recent years, and their ability to produce substantial output from compact enclosures is not theoretical despite the company name doing its best to invite the joke.
At the expensive end, JL Audio’s Fathom IWS has long been one of the reference points for concealed bass. We included the Fathom IWS in our Editors’ Choice architectural coverage because the larger 13.5-inch system combines serious output with a floating mounting arrangement designed to reduce vibration transfer into the surrounding wall structure. The tradeoff is cost and installation complexity, particularly with the larger Fathom systems.
The Bottom Line
The hardest part of disappearing a serious home theater system has always been the bottom octave. You can hide eleven speakers behind walls and ceilings, but a large subwoofer sitting next to the television rather ruins the illusion.
Monitor Audio now has a coherent answer for customers already building around the Creator Series. The WS1-W10 offers the most installation freedom, the WS2-W12 provides a substantial step up for planned theater installations, and the WS3-W12 goes after the reference-level custom market where output matters more than keeping the invoice friendly.
None of these systems changes the basic rules of low-frequency reproduction. Placement still matters, multiple subs can still produce more consistent bass across several seats, and a large freestanding subwoofer will often deliver more performance for the money. But that is not the customer Monitor Audio is chasing. These are for rooms where the speakers are supposed to disappear and the bass absolutely is not.
Pricing & Availability
Monitor Audio says the new Creator Series In-Wall Subwoofer systems will be available beginning January 2027.
U.S. pricing is as follows:
- WS1-W10 System: $2,450
- WS2-W12 System: $2,950
- WS3-W12 System: $6,150
- WS1-W10 Subwoofer: $800
- WS1-W10 BOX: $400
- IA500-S DSP Amplifier: $1,250
The WS1-W10, its rear enclosure, and the IA500-S can be purchased separately. Monitor Audio packages the WS2-W12 and WS3-W12 as complete solutions built around their corresponding enclosures and amplification.
For more information: Monitor Audio Creator Series
