Hardware configuration for 2 recievers (Anyone!)



Bronze Member
Username: Ariza700

Markham, On Canada

Post Number: 26
Registered: Feb-06
Anyone,
I have 2 reciever (Captivework 600s premium and Ariza 700, I would like to set them up in my 2 different rooms. Can some one please tell me what do I need to do hardware wise ? So normally on one TV I have 3 connections on the reciever :
1) Connection from the LNBs
2)Connection from the CABLE
3) Connection b/w reciever and TV.

How can I split this to work in 2 rooms and what extra piece of H/W I need ?
Thank you very much for your help.


Gold Member
Username: Saqeeb9000

Post Number: 1005
Registered: Oct-07
u just need a splitter..thats it ........


Bronze Member
Username: Ariza700

Markham, On Canada

Post Number: 28
Registered: Feb-06
Thx Sada. Where would I connect that splitter ?


Gold Member
Username: Nydas

Post Number: 6379
Registered: Jun-06
Ariza 700: A mere splitter will not do it, because you will be forced to view the same channel in the two rooms.

Only one Sat scanned
You need a dual LNBs (NOT twin). The two outputs are connected to two rooms and two receivers can view different channels at the same time.

More than one Sat scanned.
Method 1. If you have more than one Sat, you buy a dual LNB for each Sat and process the outputs though two separate DisEqC switches. One output from each LNB will go to one switch and the other outputs from each LNB will go though the other switch.

Methid 2. If you have DN LNBs and want to retain, the problem gets a bit more complicated and you will need to use DP34 switch which is 3 input 4 output switch. These switches can be troublesome with FTA receivers, but you can if you make sure you power them adequately by having a special power supply to output port 1 or by keeping BOTH receivers ON all the time even if one is not in use.


Gold Member
Username: Ke5aqn

IF I DONT KNOW THE ANSWER, I WILL FIND...

Post Number: 2144
Registered: Sep-06
ariza,

before we can truly help you we need to know what your receiver-lnb-switchs are you have now.
post your set up and then we can tell you what would be needed to add more receivers..


Bronze Member
Username: Ariza700

Markham, On Canada

Post Number: 29
Registered: Feb-06
Thanks folks for your replies. I have 2 LNBs (One for southasain channel and one for American Channels) these LNBs are connected through a DisEqC switch and than it goes to my CWS600P reciever. Now I have a spare Ariza700 and was hoping to connect that in other room. Let me know


New member
Username: Ghostcdn

Pescara, Abruzzo Italia

Post Number: 4
Registered: Dec-07
get a chieta switch and you should be good to go


Gold Member
Username: Ke5aqn

IF I DONT KNOW THE ANSWER, I WILL FIND...

Post Number: 2286
Registered: Sep-06
DP34 is the switch for you


Silver Member
Username: Ed_zackary

Post Number: 643
Registered: Sep-07
Upload


Silver Member
Username: Chicken_little

Post Number: 370
Registered: Dec-07
Upload


Silver Member
Username: Ed_zackary

Post Number: 648
Registered: Sep-07
Upload


Silver Member
Username: Chicken_little

Post Number: 375
Registered: Dec-07
Upload


Silver Member
Username: Ed_zackary

Post Number: 653
Registered: Sep-07
Upload
