Can a slotted port be like this? pic included
|
Silver Member Username: Langless28Post Number: 353 Registered: Dec-04 |  its the side view. done real quick on autocad during class |
|
|
Silver Member Username: LewassBoomfield Hills, MI USA Post Number: 339 Registered: Jan-06 | Yup sure can, that is just like the JL HO design except upside down. Just make sure you have the proper length and width for the proper tuned frequency. Also, obviously the port must be the same width for the entire length of it. |
|
|
Silver Member Username: LewassBoomfield Hills, MI USA Post Number: 340 Registered: Jan-06 | Also in terms of air flow, that angle is less than 90 degrees so it may be more restrictive to air flow, so I would recommend this instead: (hold on while I sketch) | |
|
Silver Member Username: LewassBoomfield Hills, MI USA Post Number: 341 Registered: Jan-06 |  |
|
|
Silver Member Username: Langless28Post Number: 354 Registered: Dec-04 | ok thanks. this is my first time im gonna built a slotted port box. i have always used pvc. but for the tuning fq i want. i would need a 4in port like 18in long, i thought i could use a 90 elbow so it would fit but its too close to call. i dont wnat to build the box and find out the sub wont fit. but when i put in the dim. into win isd. i say the port is gonna be 16" by 2" and it says it has to be like 50in long. | |
|
Gold Member Username: 54danny54Betsy layne, Kentucky..GO... USA duh Post Number: 2038 Registered: Nov-04 | lewass...did u use autocad to do that pic? i want autocad so bad but i dont want to pay lol |
|
|
Silver Member Username: LewassBoomfield Hills, MI USA Post Number: 342 Registered: Jan-06 | Haha, no I just used Paint  You should see me with photoshop, I can photo chop with the best of em |
|
|
Gold Member Username: 54danny54Betsy layne, Kentucky..GO... USA duh Post Number: 2039 Registered: Nov-04 | ha ha i used to TTRY to use photoshop lol....i suck at it horribly. now Jasc paintshop pro is a great program for that stuff...download it P2P, its nice |
|
|
Gold Member Username: BestmankindLos Angeles, CA USA Post Number: 3254 Registered: Oct-05 | lol you have to have patience to use photoshop. i once took my friends picture and put a dog head on his body. i made it look as real as possible. lol. | |
|
Silver Member Username: Langless28Post Number: 356 Registered: Dec-04 | o man do i love the powers of photoshop  |
|
|
Gold Member Username: BestmankindLos Angeles, CA USA Post Number: 3255 Registered: Oct-05 | lol thats pretty funny. | |
|
Silver Member Username: Dustin3Tigard, Or U.S. Post Number: 625 Registered: Oct-05 | wut angle is good to use (anyone) when building a box? | |
|
Bronze Member Username: Custom_boxesPost Number: 17 Registered: Mar-06 |
|
|
|
Silver Member Username: LewassBoomfield Hills, MI USA Post Number: 357 Registered: Jan-06 | Anything 90 degrees or greater will flow pretty well. I think ideally you would have a straight port with no bend.. |
