Need some help hooking up my eq


New member
Username: Xxcodytxx1

Post Number: 1
Registered: Jul-05
I have a 4 channel infinity 7541a amplifier with 2 speakers hooked up on one channel and a 10 inch kappa perfect bridged across 2 channels. My head unit has 4 rca inputs and, the rca jacks are cureently what i am using to hook up the head unit to the amp. i had the amplifier installed at the circuit city i work at and the roadshop guys took the high level input adapter. thats the basic overview of everything, but the equilizer. The equalizer has a +12 volt wire, a ground wire, a remote wire, and then wires to hook up speakers to. I also have 4 female connectors, for rca inputs one for low input right and left, subwoofer output, left and rightthen 4 stand alone wires, one is from high input, right+, and right -, then high input right + and right -. can anyone please explain how i hook this up, and if so if i need the high level input jacks? Please take into account the sub is bridged over the2 rear chanels
any help or advice would be much apreciated,

Silver Member
Username: Riebread77

Post Number: 317
Registered: Jun-05
how many inputs and outputs does the eq have?

New member
Username: Xxcodytxx1

Post Number: 2
Registered: Jul-05
it has 4 rca inputs 2 are labeled as "low inputs" and the other 2 are labeled as "subwoofer Input" There are also 4 "wire Inputs" labelled for High inputUpload

Unregistered guest
I have an old Pyramid SE425-VL-LED graphic equalizer and I need to find out the wiring diagram to hook it up. PLEASE HELP!!!

Gold Member
Username: Glasswolf

Wisteria, Lane USA

Post Number: 9773
Registered: Dec-03
email pyramid

Unregistered guest
i have the eq hooked up and it is make that er sound how can i get that out of it
