Installing a kill switch in my 1986 totota 4x4


New member
Username: Toyotadude

Post Number: 1
Registered: Jan-05
I'd like to install a kill switch on my 86 toyota 4x4. I'd like to wire it up, where the switch is wired into and exsisting switch in the car. For example: honking the horn before the car will start or Push cig lighter before car will start ect. Any thing that can't be located easy. Is it possible and/or safe? If not, I'd like to know how to wire in a "push button" or "flip" type switch Upload

Silver Member
Username: Ps1k0

Post Number: 108
Registered: Aug-04
here's a basic one

get a relay (the numbers refer to the pins on the relay)

tap into the headlight wire and connect it to 85
connect 86 to ground
cut your starter wire (under dash) and connect the key side to 30 and the starter side to 87

car will only start when the headlight is turned on.

you could also get a basic alarm

good luck
