Wiring diagram for kenwood kna-dv4100
|
New member Username: CemenemPost Number: 1 Registered: Oct-06 | hey guys i lost the wiring diagram for kenwood kna-dv4100 so i dont know where all these cables goes i am getting crazy i need help pls. IT IS KENWOOD KNA-DV4100 navigation, thanks |
|
Gold Member Username: TjmutlowPost Number: 3017 Registered: Sep-05 | go to kenwoods site |
|
New member Username: CemenemPost Number: 2 Registered: Oct-06 | i went to kenwood site nothing, i could not find it, i have been searching for 2 weeks already, i lost the wiring diagram, it was on a peper, show which cable goes where, i am sure someone out there has the same unit, i know white goes to speed, green parking brake, and pink goes to back up light. but 5 other cable left, one for illumination, other to speaker. |
|
Silver Member Username: Jenifer_contrerasTampa, Florida USA Post Number: 329 Registered: Jul-06 | Kenwood Kna-DV4100 wiring : Black----Ground wire,to car chassis Yellow---Battery wire 12V Red------Igninition wire 12V Orange---Automatic illumination control wire Brown----TEL Mute wire Pink-----Reverse detection Wire White----To the car speed signal harness Green----Parking sensor wire PS.Att.Do not cut off the holder marked "S SENS" it's containing a protection diode.Doing so will cause a fault with the car! |
|
New member Username: CemenemPost Number: 3 Registered: Oct-06 | thank you very much jenifer you are great help. |
|
Silver Member Username: Jenifer_contrerasTampa, Florida USA Post Number: 331 Registered: Jul-06 | de nada, any time! Cemenem! |
|
New member Username: CemenemACWORTH, GEORGIA USA Post Number: 4 Registered: Oct-06 | hey jeny looks like u know about these stuf, if you do not mind i need help, i am planing to install my navigation to my 2001 infiniti qx4, i have already installed the head unit, now it is time to install the nav, rear view camera and sub, camera and sub is easy, but nav, where do i connect speed wire; last time when i installed it to my 3 series bmw, i connected to the a cable in speedometer. i think speed wire goes in similar place or somewhere in trany. thank you mucho cemfbny@yahoo.com |
|
New member Username: CemenemACWORTH, GEORGIA USA Post Number: 5 Registered: Oct-06 | hey jennifer, hola, looks like u know about these stuf, if you do not mind i need help, i am planing to install my navigation to my 2001 infiniti qx4, i have already installed the head unit, now it is time to install the nav, rear view camera and sub, camera and sub is easy, but nav, where do i connect speed wire; last time when i installed it to my 3 series bmw, i connected to the a cable in speedometer. i think speed wire goes in similar place or somewhere in trany. thank you mucho cemfbny@yahoo.com |
|
Silver Member Username: Jenifer_contrerasTampa, Florida USA Post Number: 347 Registered: Jul-06 | Hola Cemenem !Ok here we are,both wires run to speedometer but I think you have to try Green/Yellow ,If not then connect to Light Blue  |
|
New member Username: CemenemACWORTH, GEORGIA USA Post Number: 6 Registered: Oct-06 | muchos gracias jenny , i have just finished installing nav, but i did not connect the speed wire, i have just seen your message, i will try as soon as i get a time, everything else works perfect, thanks alot again, by the way de donde eres? |
|
Silver Member Username: Jenifer_contrerasTampa, Florida USA Post Number: 348 Registered: Jul-06 | Colombia, Bogota! |
|
New member Username: CemenemACWORTH, GEORGIA USA Post Number: 7 Registered: Oct-06 | hey jenny ,as i have seen till now the most beautiful girls from colombia, ands i am sure your are as well, can we chat sometimes here is my e-mail adress cemfbny@yahoo.com yes by the way i am handsome turk, and my name is cem |
|
New member Username: CemenemACWORTH, GEORGIA USA Post Number: 8 Registered: Oct-06 | hey jenny thank you so much, u help me so far now i am on the way connecting speed wire, on the diagram u sent, it says green/yellow. is it green with yellow stripes, or greenish yellow color, thanks again |
|
Silver Member Username: Jenifer_contrerasTampa, Florida USA Post Number: 349 Registered: Jul-06 | about chit chat: sorry Cem,next month i am going to marry! about the wire :it's green with yellow stripes. |
|
New member Username: CemenemACWORTH, GEORGIA USA Post Number: 9 Registered: Oct-06 | that is fine, i am getting merry next month as well, i was tring to be friend only, but that's ok then, thank you very much for your help, i tried 3 cables then finally found it, i could not find it without your help. i wish you all the best on your wedding, wish you heppines together with your future husband. |
|
Silver Member Username: Jenifer_contrerasTampa, Florida USA Post Number: 350 Registered: Jul-06 | Thanks Cem for the warm words! BTW.I loved TURCIA, ANTALIA !Twice I been there...nice...wow and arabic markets it's something!!!  Yala Good Luck ! |
|
Silver Member Username: DelsolePost Number: 946 Registered: Feb-05 | big pimpin haha |
|
Silver Member Username: Jenifer_contrerasTampa, Florida USA Post Number: 366 Registered: Jul-06 | We doin' big pimpin, we spendin' cheese (Check 'em out now ) Big pimpin' On B.L.A.P.'s We doin' big pimpin' up in NYC It's just that Jigga-man, Pimp-C and B.U.N.B. Check em out now ------------ You know Joseph Kubiak I thug 'em, fu*ck 'em, love 'em, leave 'em Cause I don't fu*ckin' need 'em Take 'em out the hood Keep 'em looking good But I don't fu*ckin' feed em First time they fuss I'm breezin' Talking 'bout what's the reasons I'm a pimp in every sense of the word, bi*tch Better trust and believe 'em In a cut where I keep 'em 'Til I need a nut 'Til I need to be (in) the guts The it's beep-beep and I'm pickin 'em up Let 'em play with the dick in the truck Many chicks wanna put Jigga fist incuffs Divorce him and split his bucks Just because you got good head I'mma break bread So you can be livin' it up Sh*it I part's wit nothin Y'all be frontin' Me give my heart to a man Not for nothin' never happen' I'll be forever mackin' Heart cold as as*sas*sins, I got no passion I got no patience and I hate waitin' Hoe get your a*ss in nice song! |
|
New member Username: NoskahnCA Post Number: 1 Registered: Jan-07 | Jenifer Your the best! I had the same issue, lost thoes silly instructions. UGH! Stupid PKG was showing up enabled. Not sure if it will effect anything, but it was bugging me :-) Thanx a million -Leo |
