Composite Video Output from VCRs



New member
Username: Stillclueless

Post Number: 1
Registered: Aug-06
Does any brand of VCR provide component video output? If not, is there any way to convert composite input to component output?


Gold Member
Username: Samijubal

Post Number: 3027
Registered: Jul-04
No VCRs have component output. A DVD recorder will convert composite input to component output.


Gold Member
Username: John_s

Columbus, Ohio US

Post Number: 1076
Registered: Feb-04
Actually, D-VHS VCRs do output high and standard-def via their component outputs at 1080i,720p, 480p and 480i. I believe units such as the JVC HM-DH300000U will convert composite in to component out video.

These machines represent VHS's last harrah in the marketplace. There are some hi-def D-VHS movies available.


Gold Member
Username: John_s

Columbus, Ohio US

Post Number: 1077
Registered: Feb-04
Upload


Well, it was new a few years ago....


Gold Member
Username: Samijubal

Post Number: 3031
Registered: Jul-04
Read the specs on that recorder, it doesn't have component out.

Input and Output Connectors

Optical Digital- HDTV Proprietary (x 1 output only)
Firewire- 4-Pin (x 2 input only)

S-Video- 4-Pin (x 1 input, 1 output)
Composite Video- RCA (x 2 input, 1 output)
RF- Coaxial (x 1 input)
Audio- RCA (x 2 input, 2 output, stereo pairs)
Antenna- RF Coaxial (x 1 input, 1 output)


Gold Member
Username: John_s

Columbus, Ohio US

Post Number: 1080
Registered: Feb-04
Sorry David, I chose a site with incomplete specs.

http://www.jvc.com/product.jsp?modelId=MODL026758&pathId=15&page=2&archive=true

Without actually trying it on this D-VHS, I cannot be 100% sure the unit will automatically convert a live composite signal to component. But since it will play standard VHS through its component output, I assume it will.
